3" Trailer Ball (2" x 3-1/4" Shank, 30,000 lbs., Raw Steel) Trailer Hitch Ball CURT #CUR40089

CURT 40089 Raw Steel Trailer Hitch Ball, Gooseneck, 30,000 lbs, 3-Inch Diameter, 2 x 3-1/4-Inch Shank

  • When you need towing strength unlike anything your average trailer ball can provide, you need something that goes beyond conventional means. CURT 3" trailer balls are unparalleled in their towing capacity and design. With a wide 3" ball diameter, they offer a solid mounting place for your trailer coupler and peace of mind down every road. CURT 3" trailer hitch balls weigh in with a ball capacity of 30,000 lbs. This means they are capable of towing virtually any trailer your class 5 trailer hitch and ball mount can tow. They are also ideal for gooseneck hitch applications. The CURT 3" tow ball comes with a 2" shank diameter for added structural strength and a raw steel finish, giving it a tough layer protection against the stress of pulling large loads. Whether its commercial machinery, industrial supplies, construction equipment or farming materials, these trailer balls are built to thrive in heavy-duty applications (NOTE: Never exceed the lowest weight capacity of any towing component
  • i.e. the vehicle, hitch, trailer, etc). Also, to give them an added advantage, CURT 3" trailer balls are heat-treated and feature coarse threads. To make sure our trailer balls are fit to take on the CURT name, we put them through strenuous testing. Not only does this ensure they are capable of performing at their listed capacities, but it also gives you the confidence you need to tow that trailer wherever the highway leads. Our 3" trailer balls are made for performance and endurance and meet U.S. VESC specifications for your safety.
  • Fits 3" couplers and accepts up to 30,000 lbs. GTW
  • Constructed from high-strength raw steel
  • Heat-treated for optimum wear resistance
  • Zinc-plated hex nut and helical lock washer for secure mounting
  • Tested for safety to meet U.S. VESC V-19 specifications
  • Overall Length 3 1/4 IN
  • Overall Length 3 1/4 IN
  • Pallet Qty - XA 6.000
  • Color Raw Steel
  • Color Raw Steel
  • Finish Raw
  • Shank Length 3 1/4 IN
  • Shank Length 3 1/4 IN
  • Shank Diameter 2
  • WARNING CA Proposition 65 No
  • Warranty Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
  • Side Application Type Description - XA Blank
  • Finish - XA RAW
  • Material - XA FORGED STEEL
  • Sales Family Code - XA ACCES
  • Mount Type Description - XA Blank
  • Ball Diameter 3.000 in.
  • Ball Shank Diameter 2.000 in.
  • Gross Load 30000 lbs.
  • Torque Capacity 4550 ft/lbs.
  • Retail Height - XA 3.500
  • Rate Class - XA 60.0
  • Rate Class - XA 60.0
  • Item Class - XA OBS
  • Shipping Weight - XA 11.700
  • Parcel Allowed - XA Yes
  • Item Width - XA 0.000
  • Retail Width - XA 3.500
  • Tariff 301 - XA Yes
  • Item Height - XA 0.000
  • Item Length - XA 0.000
  • Retail Length - XA 7.750
  • Box Width in Inches - XA 4
  • Class ID 0
  • Box Length in Inches - XA 7
  • Product Weight - XA 0.000
  • Box Height in Inches - XA 2
  • Sales Family Description - XA ACCESSORIES
  • Sales Group Description - XA TRAILER BALLS
  • Ball Capacity 30,000 LBS
  • Shank Rise 0 IN
  • Torque 4550 FT LB
  • Master Case ITF14 60612314400890
  • Master Case ITF14 - XA 60612314400890
  • Master Case Length Inches - XA 8.500
  • Master Case Qty - XA 6
  • Master Case Volume Cubic Feet - XA 0.00000
  • Master Case Weight Lbs - XA 53.000
  • Master Case Width Inches - XA 6.500
  • Pallet Case Per - XA 66
  • Pallet Case Per Layer - XA 22
  • Pallet Cases Per - XA 66
  • Pallet Cases Per Layer - XA 22
  • Pallet Layer of Cases - XA 3
  • Pallet Total Height Inches - XA 25.000
  • Pallet Total Weight Per - XA 3520.000
  • Prop 65 Label Text - XA Blanks
  • Prop 65 Material - XA Unknown
  • Prop 65 Reason - XA Unknown
  • Prop 65 Warning Label Type - XA Unknown
  • Prop 65 Warning Y/N - XA NO
  • Truckload Cases Qty - XA 0
  • Truckload Pallets Qty - XA 0
  • Truckload Units Qty - XA 0
  • Truckload Volume Cubic Feet - XA 0.00000
  • Truckload Weight - XA 0
  • Container Cases Qty - XA 660
  • Container Pallet Qty - XA 10
  • Container Unit Qty - XA 3960
  • Container Volume Cubic Feet - XA 0.00000
  • Container Volume Cubic Meter - XA 0.00000
  • Container Weight KG - XA 0
  • Container Weight Lbs - XA 35200
  • Master Case Height Inches - XA 7.000
  • Master Case Inner Pack Qty - XA 0
  • Container Load Type - XA PALLETS
  • Container Type - XA 20GP
×
